SC-系列@摆动油缸-插装
无需连接钢管与管接头
油缸被设计成用通孔安装在狭窄夹具板上，具有全部功能
最小的固定空间
可完全隐藏式在夹具内
无需与安装表面垂直
可与相邻工件靠近安装
|
Clamp Force 1) pound |
Stroke inch |
Left * Turning Model Number |
Right * Turning Model Number |
Cylinder Type |
Effective Area in2 |
Max. Oil Flow 1) in3/min |
Clamp Arms 1) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Standard Arm |
Long Arm |
||||||||||
| Clamp | Total | S/A | D/A | Clamp | Uncl. | ||||||
| 475 | .32 | .66 | SCLS-22 | SCRS-22 | • | – | .12 | – | 12 | CAS-21 | CAL-22 |
| 1100 | .39 | .89 | SCLS-52 | SCRS-52 | • | – | .28 | – | 25 | CAS-51 | CAL-52 |
| 2400 | .50 | 1.09 | SCLS-122 | SCRS-122 | • | – | .63 | – | 100 | CAS-121 | CAL-122 |
| 500 | .32 | .66 | SCLD-22 | SCRD-22 | – | • | .12 | .24 | 12 | CAS-21 | CAL-22 |
| 1250 | .39 | .89 | SCLD-52 | SCRD-52 | – | • | .28 | .59 | 25 | CAS-51 | CAL-52 |
| 2600 | .50 | 1.09 | SCLD-122 | SCRD-122 | – | • | .63 | 1.23 | 100 | CAS-121 | CAL-122 |
1) Clamp force with standard clamp arm. Clamp arms are sold separately.
Clamp forces for single-acting models are reduced in order to overcome return spring force.
* For models with straight plunger movement, replace L or R with S. Example: SCSD-52.
