8000-Series Industrial Electric Pumps
The 8000 series high 压力 hydraulic electric pump is built for industrial strength
The largest hydraulic power unit in the Enerpac line and the best choice to power most large size cylinders, multiple cylinder circuits, and applications where the need for high speed requires high 流量 rates.
Panel-mounted 压力 gauge and adjustable relief valve for system 压力 control
Two-speed electric pump design, with high by-pass 压力, for rapid cylinder advance
Dual 电压 electric motor (230/460 VAC, 3 phase, 60Hz)
Full 长度 可用油量 sight tube with integral thermometer for ease in monitoring oil level and temperature
|
Used with Cylinder |
Usable Oil Capacity (gal) |
Model Number |
Pressure Rating (psi) |
Output Flow Rate (gal/min) |
Valve Type | Valve Function |
Current Draw (Amps) |
Motor Voltage* (VAC) |
Sound Level (dBA) |
Weight (lbs) |
||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1st stage |
2nd stage |
1st stage |
2nd stage |
|||||||||
| Single-acting | 18 | PEM-8218 | 3,700 | 10,000 | 4.4 | 2.0 |
Manual (VM-2) |
3-way, 2-pos. |
33.0 | 230 | 78-84 | 720 |
| 18 | PEM-8218C | 3,700 | 10,000 | 4.4 | 2.0 | 16.5 | 460 | 78-84 | 720 | |||
|
Double-acting |
18 | PEM-8418 | 3,700 | 10,000 | 4.4 | 2.0 |
Manual (VM-4) |
4-way, 3-pos. |
33.0 | 230 | 78-84 | 720 |
| 18 | PEM-8418C | 3,700 | 10,000 | 4.4 | 2.0 | 16.5 | 460 | 78-84 | 720 | |||
| 18 | PER-8418 | 3,700 | 10,000 | 4.4 | 2.0 |
Solenoid (VE43) |
4-way, 3-pos. |
33.0 | 230 | 78-84 | 765 | |
| 18 | PER-8418C | 3,700 | 10,000 | 4.4 | 2.0 | 16.5 | 460 | 78-84 | 765 | |||
* Consult Enerpac for availability of other voltages.
