SP-系列@轻型液压打孔机
低碳钢的穿透能力为12.7mm
有圆形、长方、方形冲头及压模模具供选择，解决您的打孔应用
耐用的ENERPAC单作用、弹簧回程设计
结实的钢质保管箱将各种工具与模具集中存放，便于携带与保管
含CR-400快速接头
|
Model Number |
Diameter of Punch and Die Set Model Nr. included 1) | Hydraulic set components included |
Weight pound |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SPD- 375 |
SPD- 438 |
SPD- 531 |
SPD- 563 |
SPD- 688 |
SPD- 813 |
Punch * |
Pump | Hose |
Gauge + Adaptor GP-10S GA-2 |
||
| STP-35H | – | 3/8" | – | 1/2" | 5/8" | 3/4" | SP-35 | P-392 | HC-7206 | • | 55 |
| STP-35A | – | 3/8" | – | 1/2" | 5/8" | 3/4" | SP-35 | PATG-1102N | HC-7206 | • | 63 |
| SP-35 | – | – | – | – | – | – | SP-35 | – | – | – | 35 |
| SP-35S | – | 3/8" | – | 1/2" | 5/8" | 3/4" | SP-35 | – | – | – | 40 |
| SP-35SP | – | 3/8" | – | 1/2" | 5/8" | 3/4" | SP-35 | PUD-1100B** | HC-7206 | – | 70 |
| MSP-351 | 9,5mm | 11,1mm | 13,5mm | – | 17,5mm | – | SP-35 | – | – | – | 40 |
| MSP-351PE | 9,5mm | 11,1mm | 13,5mm | – | 17,5mm | – | SP-35 | PUD-1100E** | HC-7206 | – | 70 |
* Oil capacity 76 cm3.
** PUD1100B is 115 VAC, PUD1100E is 230 VAC electric Economy pump.
1) Material thickness should not exceed hole diameter.
