RR-Series,@Double-Acting Cylinders
Enerpac double acting cylinders are rugged enough for the toughest job site uses and precision designed for high cycle industrial use.
Collar threads, plunger threads and base mounting holes for easy fixturing (on most models)
Baked enamel finish for increased corrosion resistance
Removable hardened saddles protect plunger during lifting and pressing
Built-in safety valve prevents accidental over-pressurization
CR-400 couplers included on all cylinder models
Plunger wiper reduces contamination, extending cylinder life
|
Cylinder Capacity |
Stroke |
Model Number |
Maximum Cylinder Capacity |
Cylinder Effective Area |
Oil Capacity |
Collapsed Height |
Extended Height |
Outside Diameter |
Weight | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (tons) | (in) | (ton) | (in2) | (in3) | ||||||||
| Push | Pull | Push | Pull | Push | Pull | (in) | (in) | (in) | (lbs) | |||
| 10 | 10.00 | RR-1010* | 11.1 | 4.0 | 2.23 | 0.80 | 22.33 | 8.00 | 16.13 | 26.13 | 2.88 | 28 |
| 12.00 | RR-1012* | 11.1 | 4.0 | 2.23 | 0.80 | 26.80 | 9.00 | 18.00 | 30.00 | 2.88 | 31 | |
| 30 | 8.25 | RR-308* | 32.5 | 6.0 | 6.51 | 3.00 | 53.67 | 25.00 | 15.25 | 23.50 | 4.00 | 40 |
| 14.50 | RR-3014* | 32.5 | 6.0 | 6.51 | 3.00 | 92.70 | 43.00 | 21.63 | 36.13 | 4.00 | 64 | |
| 50 | 6.13 | RR-506 | 55.3 | 11.8 | 11.06 | 3.40 | 67.77 | 21.00 | 13.06 | 19.19 | 5.00 | 67 |
| 13.13 | RR-5013 | 55.3 | 11.8 | 11.06 | 3.40 | 145.17 | 44.00 | 20.06 | 33.19 | 5.00 | 115 | |
| 20.13 | RR-5020 | 55.3 | 11.8 | 11.06 | 3.40 | 222.56 | 68.00 | 28.88 | 49.00 | 5.00 | 150 | |
| 75 | 6.13 | RR-756 | 79.6 | 17.6 | 15.92 | 4.90 | 97.58 | 29.00 | 13.69 | 19.81 | 5.75 | 92 |
| 13.13 | RR-7513 | 79.6 | 17.6 | 15.92 | 4.90 | 209.00 | 64.00 | 20.69 | 33.81 | 5.75 | 150 | |
| 100 | 6.63 | RR-1006 | 103.2 | 48.0 | 20.65 | 9.60 | 136.93 | 63.00 | 14.06 | 20.69 | 7.00 | 135 |
| 13.13 | RR-10013 | 103.2 | 48.0 | 20.65 | 9.60 | 271.17 | 126.00 | 20.63 | 33.75 | 7.00 | 205 | |
| 18.13 | RR-10018 | 103.2 | 48.0 | 20.65 | 9.60 | 374.44 | 174.00 | 27.06 | 45.19 | 7.00 | 260 | |
| 150 | 2.25 | RR-1502 | 153.5 | 74.0 | 30.71 | 14.80 | 69.11 | 33.00 | 7.72 | 9.44 | 8.00 | 110 |
| 6.13 | RR-1506 | 153.5 | 74.0 | 30.71 | 14.80 | 188.28 | 91.00 | 15.19 | 21.31 | 8.00 | 205 | |
| 13.13 | RR-15013 | 153.5 | 74.0 | 30.71 | 14.80 | 403.27 | 194.00 | 22.20 | 35.31 | 8.00 | 275 | |
| 32.13 | RR-15032 | 153.5 | 74.0 | 30.71 | 14.80 | 986.84 | 475.00 | 43.94 | 76.06 | 8.00 | 525 | |
| 200 | 6.00 | RR-2006 | 221.0 | 112.5 | 44.21 | 22.50 | 265.28 | 135.00 | 16.94 | 22.94 | 9.75 | 325 |
| 13.00 | RR-20013 | 221.0 | 112.5 | 44.21 | 22.50 | 574.78 | 293.00 | 23.94 | 36.94 | 9.75 | 440 | |
| 18.00 | RR-20018 | 221.0 | 112.5 | 44.21 | 22.50 | 795.85 | 396.00 | 30.13 | 48.13 | 9.75 | 450 | |
| 24.00 | RR-20024 | 221.0 | 112.5 | 44.21 | 22.50 | 1061.00 | 528.00 | 36.13 | 60.13 | 9.75 | 616 | |
| 36.00 | RR-20036 | 221.0 | 112.5 | 44.21 | 22.50 | 1592.00 | 792.00 | 48.13 | 84.13 | 9.75 | 845 | |
| 48.00 | RR-20048 | 221.0 | 112.5 | 44.21 | 22.50 | 2122.00 | 1056.00 | 60.13 | 108.13 | 9.75 | 1065 | |
| 300 | 6.00 | RR-3006 | 354.6 | 190.0 | 70.93 | 38.00 | 425.56 | 228.00 | 19.13 | 25.13 | 12.25 | 441 |
| 12.00 | RR-30012 | 354.6 | 190.0 | 70.93 | 38.00 | 851.12 | 456.00 | 25.13 | 37.13 | 12.25 | 608 | |
| 18.00 | RR-30018 | 354.6 | 190.0 | 70.93 | 38.00 | 1277.00 | 684.00 | 31.13 | 49.13 | 12.25 | 776 | |
| 24.00 | RR-30024 | 354.6 | 190.0 | 70.93 | 38.00 | 1702.00 | 912.00 | 37.13 | 61.13 | 12.25 | 1034 | |
| 36.00 | RR-30036 | 354.6 | 190.0 | 70.93 | 38.00 | 2553.00 | 1368.00 | 49.13 | 85.13 | 12.25 | 1385 | |
| 48.00 | RR-30048 | 354.6 | 190.0 | 70.93 | 38.00 | 3405.00 | 1824.00 | 61.13 | 109.13 | 12.25 | 1720 | |
| 400 | 6.00 | RR-4006 | 475.4 | 255.0 | 95.09 | 51.00 | 570.51 | 306.00 | 21.19 | 27.19 | 14.13 | 670 |
| 12.00 | RR-40012 | 475.4 | 255.0 | 95.09 | 51.00 | 1141.00 | 612.00 | 27.19 | 39.19 | 14.13 | 880 | |
| 18.00 | RR-40018 | 475.4 | 255.0 | 95.09 | 51.00 | 1712.00 | 918.00 | 33.19 | 51.19 | 14.13 | 1000 | |
| 24.00 | RR-40024 | 475.4 | 255.0 | 95.09 | 51.00 | 2282.00 | 1224.00 | 39.19 | 63.19 | 14.13 | 1317 | |
| 36.00 | RR-40036 | 475.4 | 255.0 | 95.09 | 51.00 | 3423.00 | 1836.00 | 51.19 | 87.19 | 14.13 | 1746 | |
| 48.00 | RR-40048 | 475.4 | 255.0 | 95.09 | 51.00 | 4564.00 | 2448.00 | 63.19 | 111.19 | 14.13 | 2162 | |
| 500 | 6.00 | RR-5006 | 565.7 | 315.0 | 113.15 | 63.00 | 678.00 | 378.00 | 22.75 | 28.75 | 15.63 | 953 |
| 12.00 | RR-50012 | 565.7 | 315.0 | 113.15 | 63.00 | 1358.00 | 756.00 | 28.75 | 40.75 | 15.63 | 1300 | |
| 18.00 | RR-50018 | 565.7 | 315.0 | 113.15 | 63.00 | 2037.00 | 1134.00 | 34.75 | 52.75 | 15.63 | 1500 | |
| 24.00 | RR-50024 | 565.7 | 315.0 | 113.15 | 63.00 | 2716.00 | 1512.00 | 40.75 | 64.75 | 15.63 | 1800 | |
| 36.00 | RR-50036 | 565.7 | 315.0 | 113.15 | 63.00 | 4074.00 | 2268.00 | 52.75 | 88.75 | 15.63 | 2210 | |
| 48.00 | RR-50048 | 565.7 | 315.0 | 113.15 | 63.00 | 5431.00 | 3024.00 | 64.75 | 112.75 | 15.63 | 2700 | |
If your application does not require high cycle, Enerpac CLRG-series cylinders may be the right alternative.
* For RR-1010 and RR-1012: N = 1.26 inch; for RR-308 and RR-3014: N = 2.20 inch.
