GBJ 系列@工业瓶式千斤顶
手柄操作省力，降低了操作人员的劳动强度
操作方便，经久耐用
采用高强度横梁和连杆，使用寿命长
设有安全溢流阀，防止过载
设有自动旁路卸荷口，防止过度伸长
底座材料厚重、面积大，增加顶升时的强度和稳定性
|
Jack Capacity |
Stroke |
Model Number |
Screw Extension |
Minimum Height |
Maximum Height |
Plunger Diameter |
Saddle Diameter |
Base Dimensions L x W |
Weight |
|---|---|---|---|---|---|---|---|---|---|
| (ton) | (in) | (in) | (in) | (in) | (in) | (in) | (in) | (lbs) | |
| 2 | 18.11 | GBJ002L | - | 22.44 | 40.55 | 1.14 | - | 5.00 x 5.00 | 13.2 |
| 2 | 3.94 | GBJ002 | 1.97 | 6.30 | 12.20 | 0.83 | 0.83 | 3.74 x 4.37 | 7.9 |
| 3 | 4.13 | GBJ003 | 2.56 | 6.61 | 13.31 | 0.94 | 0.94 | 3.74 x 4.57 | 8.6 |
| 5 | 5.91 | GBJ005 | 2.95 | 8.35 | 17.20 | 1.14 | 1.14 | 3.74 x 4.84 | 11.0 |
| 8 | 5.91 | GBJ008 | 2.95 | 8.62 | 17.48 | 1.30 | 1.46 | 3.74 x 5.43 | 13.0 |
| 10 | 5.91 | GBJ010 | 2.95 | 8.62 | 17.48 | 1.46 | 1.46 | 3.74 x 5.59 | 14.3 |
| 10 | 2.44 | GBJ010S | 1.18 | 5.16 | 8.78 | 1.46 | 1.46 | 3.74 x 5.59 | 12.1 |
| 15 | 5.91 | GBJ015 | 2.95 | 8.98 | 17.83 | 1.75 | 1.73 | 4.41 x 6.42 | 19.8 |
| 20 | 5.91 | GBJ020 | 2.95 | 9.21 | 18.07 | 2.01 | 2.28 | 5.00 x 6.73 | 26.7 |
| 20 | 4.13 | GBJ020S | 2.17 | 7.48 | 13.78 | 2.01 | 2.28 | 5.00 x 6.73 | 22.0 |
| 30 | 5.91 | GBJ030 | 2.95 | 9.53 | 18.39 | 2.26 | 2.56 | 5.59 x 7.72 | 34.2 |
| 50 | 5.91 | GBJ050 | - | 9.92 | 15.83 | 3.15 | 3.15 | 7.09 x 9.06 | 62.8 |
| 100 | 5.91 | GBJ100 | - | 11.81 | 17.72 | 4.33 | 3.70 | 11.65 x 13.11 | 191.8 |
