LU7-系列@7MPa杠杆式夹紧缸
7MPa工作压力与机床提供的压力兼容
Available in 2 kN, 3.5 kN, 5 kN, 7 kN and 9 kN clamping force capacities
Single and double acting link clamp models available
可实现左 、中、右不同的夹紧臂位置
Solid pivot lug is integral to the body for durability and repeatability
优化设计,夹紧定位重复性好
安装法兰配备BSPP和油路块油口
Nickel plated base for corrosion resistance and durability
Standard and long arms available
Models with position indicating staff available
|
夹紧ing Force at 70 bar |
Plunger Stroke mm |
Model |
Arm Position |
S/A |
D/A |
Cylinder Effective Area cm2 |
Cylinder Oil 容量 cm2 |
夹紧 Arms (sold separately) |
|
|---|---|---|---|---|---|---|---|---|---|
| Standard | Long | ||||||||
| 2 | 20.5 | LUCS-722 | Center | * | 4.2 | 8.5 |
|
|
|
| 3.5 | 20.5 | LUCS-732 | Center | * | 6.4 | 13.1 | LCAS-7232 | LCAL-7232 | |
| 5 | 26.5 | LUCS-752 | Center | * | 9.6 | 25.5 | LCAS-7572 | LCAL-7572 | |
| 7 | 26.5 | LUCS-772 | Center | * | 12.6 | 33.3 | LCAS-7572 | LCAL-7572 | |
| 9 | 32.5 | LUCS-792 | Center | * | 15.9 | 51.7 | LCAS-792 | LCAL-792 | |
| 2 | 20.5 | LUCD-722 | Center | * | 4.2 | 8.5 | LCAS-7232 | LCAL-7232 | |
| 3.5 | 20.5 | LUCD-732 | Center | * | 6.4 | 13.1 | LCAS-7232 | LCAL-7232 | |
| 5 | 26.5 | LUCD-752 | Center | * | 9.6 | 25.5 | LCAS-7572 | LCAL-7572 | |
| 7 | 26.5 | LUCD-772 | Center | * | 12.6 | 33.3 | LCAS-7572 | LCAL-7572 | |
| 9 | 32.5 |
|
Center | * | 15.9 | 51.7 | LCAS-792 | LCAL-792 | |
* Replace "C" with "R" for Right Hand or "L" for Left Hand models.
