SU7-系列@7MPa转角油缸
7MPa的工作压力与低压机床供油压力相匹配
重复夹紧精度高
安装法兰特有BSPP及油路块接口
可随意选用左旋或右旋方式
标准长度压板带有螺纹孔，用以调整螺栓或加固垫块
加长型压板可根据客户要求长度定制
新的开槽设计使用固定压板所需扭矩更小
对于长度超过标准型的压板，需要减少其工作压力与夹紧力
|
夹紧ing Force at 70 bar kN |
Total Plunger 行程 mm |
夹紧ing 行程 mm |
Model Number * | Arm Rotation |
Single Acting |
Double Acting |
Cylinder Effective Area cm2 |
Cylinder Oil 容量 cm2 |
夹紧 Arms (sold separately) |
|
|---|---|---|---|---|---|---|---|---|---|---|
| Standard | Long | |||||||||
| 2 | 22.1 | 12 | SURS-722 | Right Hand | * | 3.02 | 6.7 |
|
|
|
| 3.5 | 22.1 | 12 | SURS-732 | Right Hand | * | 5.28 | 11.7 |
|
|
|
| 5 | 22.1 | 12 | SURS-752 | Right Hand | * | 7.54 | 16.7 |
|
|
|
| 7 | 22.1 | 12 | SURS-772 | Right Hand | * | 10.3 | 22.8 |
|
|
|
| 9 | 22.1 | 12 | SURS-792 | Right Hand | * | 13.19 | 29.1 |
|
|
|
| 20 | 22.1 | 12 | SURS-7202 | Right Hand | * | 30.44 | 67.3 |
|
|
|
| 2 | 22.1 | 12 | SURD-722 | Right Hand | * | 3.02 | 6.7 |
|
|
|
| 3.5 | 22.1 | 12 | SURD-732 | Right Hand | * | 5.28 | 11.7 |
|
|
|
| 5 | 22.1 | 12 | SURD-752 | Right Hand | * | 7.54 | 16.7 |
|
|
|
| 7 | 22.1 | 12 | SURD-772 | Right Hand | * | 10.3 | 22.8 |
|
|
|
| 9 | 22.1 | 12 | SURD-792 | Right Hand | * | 13.19 | 29.1 |
|
|
|
| 20 | 22.1 | 12 | SURD-7202 | Right Hand | * | 30.44 | 67.3 |
|
|
|
* Replace "R" with "L" for Left Hand models.
* Add "S" to the end of the model number for position sensing staff
