IPR-系列@滚架式压床

IPR-系列@滚架式压床 The Enerpac roll frame press has a 容量 of 50 to 200 tons Quality welded frame for maximum strength and long life Frame rolls easily on four steel roller bearings Hydraulic clamp cylinders lock frame into position Exclusive “Hydra-Lift™” b

IPR-系列@滚架式压床
The Enerpac roll frame press has a 容量 of 50 to 200 tons
Quality welded frame for maximum strength and long life
Frame rolls easily on four steel roller bearings
Hydraulic clamp cylinders lock frame into position
Exclusive “Hydra-Lift™” bolster for effortless adjustment of the vertical daylight
Standard roller head design allows movement of the cylinder from side to side
All roll frame press models in the Quick Selection Chart have been matched to a pump, cylinder, hoses and gauge, offering the complete package
Roll Frame design features a stationary bed with the ability to support heavy loads

Press Capacity Vertical
Daylight
Max. Bed Width Electric Pump Model
Number
Double-acting Cylinder Speed Weight
inch/sec
inch Model
Number
stroke Model
Number
Rapid
Advance
Pressing pound
ton min max. inch inch
50 6.00 37.12 28.75 ZE4420SB-N IPR-5075 13.13 RR-5013 1.0 11.1 1,961
100 6.28 41.28 35.00 ZE5420SG-N IPR-10075 13.13 RR-10013 1.5 10.3 3,849
200 11.00 51.00 48.00 ZE5420SG-N IPR-20075 13.00 RR-20013 3.1 22.1 7,869
