ZW-系列@电动工装夹具泵
Enerpac Z-Class high efficiency single-stage electric workholding pumps
Pallet coupling pumps
Provides momentary 压力 and 流量 to fixture
Ideal for pallet disconnect systems
Continuous connection pumps
Provides solenoid control of one single- or double-acting circuit
Includes pilot operated check valve ensuring 压力 is maintained in circuit
Single station DO3 pumps
Industry standard mounting for manual or electric valves
Options: backlit LCD, heat exchanger, 压力 transducer, level & temperature switches and roll bars
SAE Ported for Remote Valves
Z系列泵效率高，流量更大，旁路压力高，散热性能好，工作电流较同类产品低18%
全封闭式带风冷散热装置电动机，延长泵的使用寿命及适应苛刻的工作环境
阀的种类和油箱规格可以提供特殊的形式以满足更多要求的工装夹具的应用
高强度的模塑电控箱保护电路，电机及数显装置，使泵避免冷却液和污染物带来的危害
|
Output Flow at 5000 psi in3/min |
Motor |
Motor Voltage Volt-phase at 60Hz |
Usable Oil Capacity gal |
Pallet Coupling Pumps Model Number |
Continuous Connection Pumps Model Number |
Single Station DO3 Pumps Model Number |
SAE Ported for Remote Valving Model Number |
Weight lbs |
|---|---|---|---|---|---|---|---|---|
| 40 | 1.0 | 115-1 | 2 | ZW3408DB-FT | ZW3408FB-FT | ZW3008GB-11 | ZW3008HB-FT01 | 115 |
| 40 | 1.0 | 115-1 | 2.5 | ZW3410DB-FT | ZW3410FB-FT | ZW3010GB-11 | ZW3010HB-FT01 | 134 |
| 40 | 1.0 | 230-1 | 2 | ZW3408DI-FT | ZW3408FI-FT | ZW3008GI-11 | ZW3008HI-FT01 | 115 |
| 40 | 1.0 | 230-1 | 2.5 | ZW3410DI-FT | ZW3410FI-FT | ZW3010GI-11 | ZW3010HI-FT01 | 134 |
| 60 | 1.0 | 115-1 | 2.5 | ZW4410DB-FT | ZW4410FB-FT | ZW4010GB-11 | ZW4010HB-FT01 | 120 |
| 60 | 1.0 | 230-3 | 2.5 | ZW4410DG-FT | ZW4410FG-FT | ZW4010GG-11 | ZW4010HG-FT01 | 120 |
| 60 | 1.0 | 460-3 | 2.5 | ZW4410DJ-FT | ZW4410FJ-FT | ZW4010GJ-11 | ZW4010HJ-FT01 | 120 |
| 120 | 1.5 | 115-1 | 2.5 | ZW5410DB-FT | ZW5410FB-FT | ZW5010GB-11 | ZW5010HB-FT01 | 130 |
| 120 | 1.5 | 230-3 | 2.5 | ZW5410DG-FT | ZW5410FG-FT | ZW5010GG-11 | ZW5010HG-FT01 | 130 |
| 120 | 1.5 | 460-3 | 2.5 | ZW5410DJ-FT | ZW5410FJ-FT | ZW5010GJ-11 | ZW5410HJ-FT01 | 130 |
