700, 900-系列@高压软管
Enerpac high 压力 hydraulic hoses feature crimped-on rubber strain relief for improved life and durability on all models.
热塑性塑料软管（700-系列）
用于要求特殊的应用，安全系数为4：1
最大工作压力为700bar
四层设计，其中两层为高强度钢丝编织层
外部保层为聚氨酯材料，提供最大耐磨损能力
压力下体积膨胀小，利于提高安全系统的效率
所有型号都配有波纹状橡胶护套防止损伤以提高寿命与耐用性
Heavy-duty Rubber Hoses (900-Series)
The most complete offering of hydraulic hoses: 35 models up to 50 feet in 长度
Rubber coated with two layers of steel wire braids
Designed to comply with Material Handling Institute IJ-100 hose specification
Flexible, with little “memory”, is the best choice for long hose runs
|
Internal Diameter |
Hose End Assemblies and Couplers | Hose Length | 700-Series Thermo-plastic | 900-Series Heavy-duty rubber | |||
|---|---|---|---|---|---|---|---|
| in | End one | End two | ft | Model Number | Wt. (lbs) | Model Number | Wt. (lbs) |
| .25 | 1/4” NPTF | 1/4” NPTF | 6 | - | H-9206Q | 2.6 | |
| 3/8” NPTF | 6 | - | H-9206S | 2.6 | |||
| A-630 | 6 | HB-7206QB | 2.4 | HB-9206QB | 3.1 | ||
| AH-630 | 6 | - | HB-9206Q | 2.9 | |||
| CH-604 | 6 | HC-7206Q | 2.3 | HC-9206Q | 3.0 | ||
| 3/8” NPTF | 3/8” NPTF | 2 | H-7202 | 1.2 | H-9202 | 1.6 | |
| 3 | H-7203 | 1.5 | H-9203 | 1.9 | |||
| 6 | H-7206 | 2.0 | H-9206 | 2.6 | |||
| 10 | H-7210 | 3.0 | H-9210 | 3.9 | |||
| 20 | H-7220 | 6.2 | H-9220 | 8.0 | |||
| 30 | H-7230 | 10.0 | H-9230 | 13.0 | |||
| 50 | H-7250 | 15.4 | H-9250 | 22.0 | |||
| A-604 | - | - | |||||
| 6 | HA-7206B | 2.5 | HA-9206B | 3.2 | |||
| 10 | - | HA-9210B | 4.5 | ||||
| AH-604 | - | - | |||||
| 3 | - | HA-9203 | 2.1 | ||||
| 6 | HA-7206 | 2.2 | HA-9206 | 2.9 | |||
| 10 | HA-7210 | 3.2 | HA-9210 | 4.2 | |||
| AH-630 | 6 | HB-7206 | 2.2 | HB-9206 | 2.9 | ||
| C-604 | 3 | HC-7203B | 2.2 | HC-9203B | 2.9 | ||
| 6 | HC-7206B | 2.8 | HC-9206B | 3.7 | |||
| 10 | HC-7210B | 3.9 | HC-9210B | 5.0 | |||
| CH-604 | 3 | HC-7203 | 1.7 | HC-9203 | 2.2 | ||
| 6 | HC-7206 | 2.3 | HC-9206 | 3.0 | |||
| 10 | HC-7210 | 3.3 | HC-9210 | 4.3 | |||
| 20 | HC-7220 | 6.4 | HC-9220 | 8.3 | |||
| CH-604 | CH-604 | 6 | HC-7206C | 2.4 | HC-9206C | 3.1 | |
| 50 | HC-7250C | 15.4 | HC-9250C | 20.0 | |||
| .38 | 3/8” NPTF | 3/8” NPTF | 6 | H-7306 | 3.5 | H-9306 | 4.6 |
| 10 | H-7310 | 5.4 | H-9310 | 7.0 | |||
| 20 | H-7320 | 10.0 | H-9320 | 13.0 | |||
| 30 | H-7330 | 16.2 | H-9330 | 21.0 | |||
| 50 | H-7350 | 15.2 | H-9350 | 33.0 | |||
| CH-604 | 6 | HC-7306 | 3.4 | HC-9306 | 4.9 | ||
| 8 | - | HC-9308 | 6.2 | ||||
| 10 | HC-7310 | 5.6 | HC-9310 | 7.3 | |||
