NS-系列@大口径螺母破切器
专为ANSI B16.5/BS1560标准法兰设计
单作用，弹簧回位或双作用快速回位
刀头采用三刃设计，一个刀头可提供三个刀刃
可更换的工作头提供了最大限度的螺母适应性
刀头伸长距离可方便预设，确保螺母破切的同时不损坏螺栓
牢固的手柄使工作更可靠、操作更便利
缸体镀镍处理，保护工具不受腐蚀及恶劣环境影响
内置安全阀提供过载保护
|
Hexagon Nut Range** |
Bolt Range |
Capacity |
Oil Capacity |
Model Number* | Weight |
|---|---|---|---|---|---|
| (in) | (in) | (ton) | (in3) | (lbs) | |
| 2.75 - 3.13 | 1.75 -2.00 | 103.2 | 23.0 | NS-7080 | 81.4 |
| 2.75 - 3.50 | 1.75 -2.25 | 103.2 | 23.0 | NS-7085 | 82.7 |
| 2.75 - 3.88 | 1.75 - 2.50 | 103.2 | 23.0 | NS-7095 | 84.9 |
| 2.75 - 4.25 | 1.75 - 2.75 | 103.2 | 23.0 | NS-70105 | 87.1 |
| 4.25 - 4.63 | 2.75 - 3.00 | 192.5 | 50.0 | NS-110115 | 151.6 |
| 4.25 - 5.38 | 2.75 - 3.50 | 192.5 | 50.0 | NS-110130 | 158.3 |
*NS-Series Nut Splitters ship in two cases: One containing the NSC Cylinder and one containing the NSH Cutting Head. Assembly required.
**Maximum allowable hardness to split is HRc-44.
