TQ-700, Lightweight Electric Torque Wrench Pump

TQ-700, Lightweight Electric Torque Wrench Pump Optimized 流量 technology delivers up to 50% faster bolting than competing pumps Compact and lightweight design fits through tight openings and provides easy handling Built-in protection for controls and

Optimized 流量 technology delivers up to 50% faster bolting than competing pumps
Compact and lightweight design fits through tight openings and provides easy handling
Built-in protection for controls and gauge for job-site durability
IP55 * rating for superior dust and water protection
Advanced IEC Motor provides for quiet, continuous operation, high 电压 tolerance, and low maintenance
Simple 压力 setting and convenient pendant control for hassle-free operation

Performance	For Use with Torque Wrenches		Pressure Rating (psi)	Model Number	Motor Electrical Specification	Useable Oil Capacity (gal)	Weight (no oil) (lbs)
Optimal	S1500 S3000 S6000	W2000 W4000 W8000	10,000	TQ-700B	115V-1 ph, 60 Hz	1	68
				TQ-700B	115V-1 ph, 60 Hz		68
				TQ-700E	230V-1 ph, 50 Hz		66
Acceptable	S11000 S25000	W15000 W22000 W35000		TQ-700E	230V-1 ph, 50 Hz		66
				TQ-700I	230V-1 ph, 60 Hz		66
				TQ-700I	230V-1 ph, 60 Hz		66

* IP Ratings

The IP Code (or Ingress Protection Rating) consists of the letters IP followed by two digits. The IP Code classifies and rates the degrees of protection provided against the intrusion of solid objects (including body parts like hands and fingers), dust, accidental contact, and water in mechanical casings and with electrical enclosures.

A rating of IP55 means that the TQ700 offers complete protection against contact with mechanical or electrical components. Dust will not enter in a sufficient quantity to interfere with the operation of the equipment. Additionally, the IP55 rating means the pumps will not be damaged or become unsafe during operation when water is splashed or sprayed against the enclosure from any direction.
