FN, MF, BS-系列@油缸
应用于最适宜的安装和夹具适用性可适合各种应用场合
安装法兰
用于拧紧油缸以适合应用
法兰螺母
用于在任意位置安装螺纹缸体或油缸
接触螺钉
在您的夹紧应用中可允许油缸工作为一个数据点，并在油缸用于推进场合时保护活塞
|
Mounting Thread inch |
Flange Nut Model Nr. |
Mounting Flange Model Nr. |
Spherical Contact Bolt Model Nr. |
Yoke Model Nr. |
Mounting Bracket Cylindrical Model Nr. |
Mounting Bracket Rectangular Model Nr. |
|---|---|---|---|---|---|---|
| #6-32 UNC | – | – | BS-21 | – | – | – |
| #8-32 UNC | – | – | BS-41 | – | – | – |
| .250-28 UNF | – | – | BS-61 | – | – | – |
| .313-24 UNF | – | – | BS-81 | Y-3121 | – | – |
| .375-16 UNC | – | – | BS-91 | – | – | – |
| .500-13 UNC | – | – | BS-101 | – | – | – |
| .500-20 UNF | FN-121 | MF-121 | – | – | – | – |
| .750-16 UNF | FN-201 | MF-201 | – | – | – | – |
| 1.000-12 UNF | FN-251 | MF-251 | – | – | – | – |
| 1.125-16 UN | FN-281 | MF-281 | – | – | – | – |
| 1.250-16 UN | FN-301 | – | – | – | – | – |
| 1.313-16 UN | FN-331 | MF-331 | – | – | ||
| 1.375-18 UNEF | FN-351 | MF-351 | – | AW-5 | ||
| 1.500-16 UN | – | – | – | – | AW-53 | AW-51 |
| 1.625-16 UN | FN-421 | MF-421 | – | – | – | – |
| 1.875-16 UN | FN-481 | MF-481 | – | – | – | AW-89 |
| 2.125-16 UN | FN-551 | MF-551 | – | – | – | – |
| 2.250-14 UN | – | – | – | – | – | AW-102 |
| 2.500-16 UN | FN-651 | MF-651 | – | AW-19 | ||
| 2.750-16 UN | – | – | – | – | AW-121 | – |
| 3.125-16 UN | FN-801 | MF-801 | – | – | – | AW-90 |
