ZU4-系列@电动泵
效率高，流量大，旁路压力高，冷却性能好，工作电流较同类泵低18%
1.7HP强力通用电动机，提供更高的功率/重量比及优良的低压运行性能
高强度模塑屏罩保护电机和电气元件，绝缘手柄绝缘性能良好，人体工程设计，便于携带
Pro Series pump only
* LCD数字显示装置可提供其他便携式电动泵从未有过的系统诊断和信息显示功能（电磁阀标配，手动阀可选）
AutoCycle feature provides continuous cycle operation of the torque wrench as long as the advance button is pressed (pump can be used with or without auto cycle feature)
| Pump Type |
Used with Cylinder |
Valve Function |
Valve Type 1) |
Pump Control |
Usable Oil Cap. (gal) |
Model Number 115 VAC 2) 1 Phase |
Pro Product Weight w/oil 3) (lbs) |
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
Classic | STD Electric | Pro Electric | |||||
|
• | • | • | VM22 | Manual | 1.0 | ZU4704RB | ZU4704MB | ZU4704LB | 59 | ||
| • | • | • | VM22 | Manual | 2.0 | ZU4708RB | ZU4708MB | ZU4708LB | 69 | |||
| • | • | • | • | VM33 | Manual | 2.0 | ZU4308RB | ZU4308MB | ZU4308LB | 70 | ||
| • | • | • | • | VM33 | Manual | 5.0 | ZU4320RB | ZU4320MB | ZU4320LB | 109 | ||
| • | • | • | • | VM43 | Manual | 2.0 | ZU4408RB | ZU4408MB | ZU4408LB | 70 | ||
| • | • | • | • | VM43 | Manual | 5.0 | ZU4420RB | ZU4420MB | ZU4420LB | 109 | ||
|
• | • | • | VM22 |
|
1.0 | ZU4704PB | ZU4204JB | ZU4204KB | 60 | ||
| • | • | • | VM22 | Remote(Man.) | 2.0 | ZU4708PB | ZU4208JB | ZU4208KB | 70 | |||
| • | • | • | VM22 | Remote(Man.) | 5.0 | ZU4720PB | ZU4220JB | ZU4220KB | 109 | |||
| • | • | • | • | VM33 | Remote(Man.) | 2.0 | ZU4308PB | ZU4308JB | ZU4308KB | 71 | ||
| • | • | • | • | VM43 | Remote(Man.) | 2.0 | ZU4408PB | ZU4408JB | ZU4408KB | 71 | ||
| • | • | • | • | VM43 | Remote(Man.) | 5.0 | ZU4420PB | ZU4420JB | ZU4420KB | 110 | ||
|
• | • | • | VE32D | Remote | 1.0 | N/A | N/A | ZU4104DB | 63 | ||
| • | • | • | VE32D | Remote | 2.0 | N/A | N/A | ZU4108DB | 73 | |||
| • | • | • | VE32D | Remote | 5.0 | N/A | N/A | ZU4120DB | 112 | |||
| - | - | - | - | - | - | - | ||||||
| - | - | - | - | - | - | - | ||||||
| - | - | - | - | - | - | - | ||||||
|
• | • | • | VE32 | Remote | 1.0 | N/A | N/A | ZU4204SB | 63 | ||
| • | • | • | VE32 | Remote | 2.0 | N/A | N/A | ZU4208SB | 73 | |||
| • | • | • | • | VE33 | Remote | 2.0 | N/A | N/A | ZU4308SB | 85 | ||
| • | • | • | • | VE43 | Remote | 2.0 | N/A | N/A | ZU4408SB | 85 | ||
| • | • | • | • | VE43 | Remote | 5.0 | N/A | N/A | ZU4420SB | 124 | ||
| - | - | - | - | - | - | - | ||||||
1) See valves section for technical information on valve types.
2) See custom order matrix on catalog page for other voltage options.
3) Subtract 3 lbs. for STD Electric models.
All models meet CE safety requirements. "E" voltage versions also meet all requirements of the European EMC-Directive.
